Pulsar PTX3584RS GEN2 Ball Bearing Turbo

From £615.47 Inc. VAT

Finance Calculator

A loan from Omni Capital can help you spread the cost of your purchase with fixed monthly payments. Please select a deposit amount and loan term below to see a representative example of your purchase using finance.

Deposit Amount

Choose a deposit amount that suits you, ranging from 20% (£124) to 50% (£307) of the purchase amount.

-
£
+

Loan Terms

Choose from the available loan products the term and APR that best suits your needs. A longer term reduces monthly payment amount but may increase the amount of interest paid.

Term Length
First Instalment:
Monthly Instalment:
Omni Powered by Autify Digital Ltd

Representative Example

Please note, Omni Capital Retail Finance is only available to UK residents over 18, subject to terms and conditions. To apply for finance, please add the product to your shopping cart, proceed through checkout and select "Pay by Finance" as your payment option. You will be redirected to the Omni Finance website, where you can complete the application form online. Your purchase will be delivered to the address provided on your application

You can get a min loan amount of £250.00 and max loan amount of £25,000.00.

Omni Finance Calculator

For product advice call 0345 009 5641 or Click Here to send an email

Description

Pulsar PTX3584RS Gen 2 Please note, T51R housing option requires an extra 7 days handling time Recommended displacement 2.0 to 5.0 litres with power outputs up to 1000hp possible. ‘Dual ceramic ball bearing system- 67*84mm Billet compressor wheel- 68*62mm “RS” Gen2 turbine wheel 0.83, 1.01 A/R dual v-band turbine housing, T3 0.63, 0.82 V-Band outlet turbine housings available V-Band Flange kit(s) for the exhaust housing included Gen2 cover with integrated speed sensor port Compressor Housing: 4′ inlet, 2.5” outlet, 0.72A/R, Anti-surge 10 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology Inconel 713c Gen2 9 Blade Turbine Wheel SPEC Billet Compressor Wheel: 67.3/84.4, 10+0 Blades; Compressor Housing: 4” inlet, 2.5” outlet, 0.72 A/R, Anti-surge; Turbine Wheel: 68/62.3mm; (“RS” blade profile) Turbine Housing: T3 inlet, V band outlet, 0.82 A/R; Turbine housing Outlet flange&clamp fit: 3” OD tubing, slip on & weld. It’s strongly recommended to run water cooling to aid reliability.

Additional information

Manufacturer

Turbo Model

PTX3584RS GEN2

Turbo Bearing Type

Ball Bearing

Turbo Wastegate

External Wastegate

Compressor Housing

No compressor housing, Standard, T51R

Turbine Housing

Dual V-BAND 0.83 A/R, Dual V-BAND 1.01 A/R, No Turbine Housing, SS Dual V-BAND 0.82 A/R, SS Dual V-BAND 0.82 A/R + T25 adapter, SS Dual V-BAND 0.82 A/R + T3 Adapter, SS Dual V-BAND 1.03 A/R + T25 Adapter, SS Dual V-BAND 1.03 A/R + T3 Adapter, Stainless Steel Dual V-BAND 0.64 A/R, Stainless Steel Dual V-BAND 0.64 A/R + T25 adapter, Stainless Steel Dual V-BAND 0.64 A/R + T3 adapter, Stainless Steel Dual V-BAND 1.03 A/R, T3 0.63 A/R V-BAND, T3 0.82 A/R V-BAND, T3 1.06 A/R V-BAND, T4 0.82 A/R V-BAND, T4 Divided 0.85 A/R (4 weeks lead time)

SKUPULSAR-PTX3584RS-GEN2
